Qaabka badeecada ee 12KV jabiyaha wareegga gudaha ee lagala bixi karo waa ZN63(VS1) -12. Alaabtu waxay ka kooban tahay habka hawlgalka isku-dhafan iyo jebiya wareegga, iyo wareegga ugu muhiimsan wuxuu isticmaali karaa isku-xidhka tiirka si buuxda u daboolan si loo gaaro yaraynta, isku halaynta sare, iyo hawlgalka dayactir la'aanta. Waxa lagu isticmaali karaa qalabka beddela ee danab dhexdhexaadka ah sida taxanaha KYN28.
|
danab lagu qiimeeyay |
12KV/17.5KV |
|
Inta jeer ee la qiimeeyay |
50Hz |
|
Hilaaca la qiimeeyay ee u adkaysta danabka (qiimaha ugu sarreeya) |
75kV |
|
La qiimeeyay inta jeer ee tamarta wakhtiga gaaban u adkeysaneysa danab (1 daqiiqo) |
42kV |
|
Hadda la qiimeeyay |
630/1250A |
|
Lagu qiimeeyay qulqulka wareega-gaaban |
20/25kA |
|
La qiimeeyay samaynta wareega gaaban ee hadda (qiimaha ugu sarreeya) |
50/63kA |
|
Lagu qiimeeyay waqti gaaban u adkaysanayo hadda iyo muddada |
20/4kA/S |
|
Lagu qiimeeyay jabinta wareega gaaban ee hadda iyo tirada hawlgallada goynta |
30 jeer |
|
Waqtiga xidhitaanka |
35-70ms |
|
Waqtiga furitaanka (ee wareegga wareegga) |
20-50ms |
|
Nolosha makaanikada |
10,000 jeer |
|
Awoodda kaydinta tamarta la qiimeeyay iyo danab shaqaynaysa |
AC220/110V DC220/110V |
|
Celceliska xawaaraha xidhitaanka |
0.5-0.8m/s |
|
Celceliska xawaaraha beddelka |
0.9-1.2m/s |
|
Farqiga xiriirka |
11 ± 1mm |
|
Xiriirka xad dhaafka ah |
3.5 ± 0.5mm |
|
Xidhiidhka xidhitaanka wakhtiga soo kabashada |
≤ 2m/s |
1.The heerkulka hawlgalka waa -10 ℃ in 40 ℃, iyo kaydinta iyo gaadiidka waa la ogol yahay at -30 ℃;
2. Dhererka shaqada waa inuusan dhaafin 1000m. Haddii dhererku kordho, heerka dahaarka ee la qiimeeyay waa in la kordhiyaa si waafaqsan;
3. Heerka xoojinta seismic ee lagu dabaqi karo waa inuusan dhaafin cabbirka 8;
4. 12kV Gudbinta Wareega Gudaha ee Lagala Soo bixi Karo waxay ku haboontahay meelaha aan dabka, qaraxa, wasakhda daran, daxalka kiimikaad, iyo gariirka rabshadaha wata.
